DONNÉES GÉNÉRALES |
Année du premier vol (ou de design, si seul projet) |
1947 |
Pays | USA |
Designer(s) | Schweizer Aircraft Corporation |
Premier constructeur | Schweizer Aircraft Corporation, Elmira, New-York |
Type d'appareil | Planeur |
Fonction | Performance |
SPÉCIFICATIONS TECHNIQUES |
Envergure | 15.5 m |
Longueur | 6.72 m |
Hauteur | -- |
Allongement | 15.75 |
Surface alaire | 15.3 m2 |
Profil aile | Emplanture NACA 23012, milieu, NACA 43012A, saumon NACA 23009 |
Masse à vide | 214 kg |
Masse maxi | 236 kg |
Charge alaire | 29.4 kg/m2 |
Vitesse mini | 58 km/h |
Vitesse maxi | 240 km/h |
Finesse maxi | 29 |
Taux de chute mini | 0.66 m/s à 61 km/h |
Nb sièges | 1 |
Ballast | 118 L |
Structure | -- |
Liens WEB | Site : UIUC Applied Aerodynamics Group . NACA 23012 airfoil. (2010-06-18 JM) Site : UIUC Applied Aerodynamics Group . NACA 23012 fichier DAT. (2010-06-18 JM) |
Livres | Sailplanes 1945-1965 par SIMONS, Martin (2001) [p. 127. Photo + 3-vues + specs + description]. The world's sailplanes par OSTIV (1958) [p. 178, 181 - 184. Photo + 3-vues + specs + description]. |
Autres sources | Reportage sur le SGS 1-21 NX91861 dans RCSD novembre 2007 Soaring septembre-octobre 1947 page p. Publicité + Photo. Soaring septembre-octobre 1947 p 6. Photo. Soaring juillet-août 1957 p 18. Texte + Photo. Soaring février 1960 p 6. Photo. Soaring mars 1961 p 2. Grande photo. |
