DONNÉES GÉNÉRALES |
Année du premier vol (ou de design, si seul projet) |
1955 |
Pays | Angleterre |
Designer(s) | Slingsby Sailplanes Ltd |
Premier constructeur | Slingsby Sailplanes Ltd, Kirbymoorside, Yorkshire |
Type d'appareil | Planeur |
Fonction | Performance |
SPÉCIFICATIONS TECHNIQUES |
Envergure | 18.2 m |
Longueur | 7.62 m |
Hauteur | -- |
Allongement | 20.5 |
Surface alaire | 16.1 m2 |
Profil aile | Emplanture NACA 63(3)620, saumon NACA 4415 |
Masse à vide | 256 kg |
Masse maxi | 358 kg |
Charge alaire | 22.2 kg/m2 |
Vitesse mini | 58 km/h |
Vitesse maxi | 216 km/h |
Finesse maxi | 36 |
Taux de chute mini | 0.55 m/s à 70 km/h |
Nb sièges | 1 |
Structure | -- |
Constructeur(s) |
| ||||||
Infos techniques | Roue fixe et patin A development of the Type 41 Skylark 2, with wingspan increased to 18 metres; the following types were produced: Skylark 3 (or 3A) - Initial version; prototype BGA 735 first flown in July 1955. Most subsequently modified to Skylark 3B Skylark 3B - cockpit lengthened by 3 inches; some later modified to Skylark 3F standard Skylark 3C - version of Skylark 3A for Netherlands with strengthened wing spars Skylark 3D - version of Skylark 3B for North America with strengthened wing spars Skylark 3E - one-off with modified outer wings and ailerons; subsequently converted to Skylark 3B Skylark 3F - New tailplane of increased span and reduced chord; enlarged canopy Skylark 3G - fitted with new ailerons of increased span and reduced chord | ||||||
Histoire résumée | -- | ||||||
Liens personnalités | Pas de personnalité associée. | ||||||
Remarques | Voir Slingsby T-43 Skylark 3. |
Liens WEB | Site : UIUC Applied Aerodynamics Group's . NACA 4415 airfoil. (2010-08-01 JM) Site : UIUC Applied Aerodynamics Group's . NACA 4415 fichier DAT. (2010-08-01 JM) |
Livres | British Gliders and Sailplanes 1922-1970 par ELLISON, Norman (1971) [p. 212, 264. Note + specs]. The world's sailplanes par OSTIV (1958) [p. 108, 109, 111 - 114. Photo, 3-vues + specs + description]. |
