DONNÉES GÉNÉRALES |
Année du premier vol (ou de design, si seul projet) |
1989 |
Pays | Afrique du Sud |
Designer(s) | CELLIER, Peter & JORDAAN, François |
Premier constructeur | Celair Manufacturing and Export (Afrique du Sud) |
Type d'appareil | Planeur |
Fonction | Voltige |
SPÉCIFICATIONS TECHNIQUES |
Envergure | 11.2 m |
Longueur | -- |
Hauteur | -- |
Allongement | 10.9 |
Surface alaire | 11.54 m2 |
Profil aile | Wortmann FX-71-L-150/25 |
Masse à vide | 265 kg |
Masse maxi | 385 kg |
Charge alaire | 33.36 kg/m2 |
Vitesse mini | -- |
Vitesse maxi | -- |
Finesse maxi | 25 |
Taux de chute mini | 0.89 m/s |
Nb sièges | 1 |
Structure | glass fiber/ epoxy / aramid |
Constructeur(s) |
| ||||||
Infos techniques | -- | ||||||
Histoire résumée | The Celstar, specifically designed to JAR 22 specifications for competitive aerobatics ( 10 g), first flew in 1989. It has full span mass balanced ailerons. Airbrakes are used for appoach control. The main wheel is retractable. Il y aurait eu 6 exemplaires construits (?). The first of six Celstar GA-1 aerobatic gliders has been exported to the USA. Celstar's South African manufacturer, Celair Manufacturing and Export, says: "This a first in the history of South Africa where an aircraft which is locally manufactured is exported". A second Celstar has since been exported to Switzerland.[Flight Archiv] | ||||||
Liens personnalités | Pas de personnalité associée. |
Liens WEB | Site : Alex Sailplane Directory . Note + photo + specs. (2010-03-24 CL) Site : SAGA - Swiss Aerobatic Gliding Association . Texte + photo + specs. (2010-03-24 CL) Site : Flight Archiv . Note (exportation vers les USA). (2010-03-24 CL) |
Livres | Pas de livre référencé. |
Autres sources | "Essai : Celair GA-1 Celstar", par Peter Selinger, Vol à Voile n° 35 |
