DONNÉES GÉNÉRALES |
Année du premier vol (ou de design, si seul projet) |
1955 |
Pays | Autriche |
Designer(s) | MUSGER, Erwin |
Premier constructeur | Josef Oberlerchner, Holzindustrie, Spittal /Drau |
Type d'appareil | Planeur |
Fonction | Performance |
SPÉCIFICATIONS TECHNIQUES |
Envergure | 16.4 m |
Longueur | 7.11 m |
Hauteur | -- |
Allongement | 18.54 |
Surface alaire | 14.207 m2 |
Profil aile | NACA 63-015 |
Masse à vide | 240 kg |
Masse maxi | 360 kg |
Charge alaire | 25.3 kg/m2 |
Vitesse mini | -- |
Vitesse maxi | -- |
Finesse maxi | 32 à 85 km/h |
Taux de chute mini | 0.66 m/s à 68 km/h |
Nb sièges | 1 |
Structure | Bois et toile |
Constructeur(s) |
| ||||||
Infos techniques | -- | ||||||
Histoire résumée | Evolution de la série des Mg-19. Monoplace de haute performance. Construction classique en contreplaqué. L'état de surface a été particulièrement soigné. Profitant de l'expérience faite avec le Mg-19, le longeron principal du Mg-23 a été reporté le plus en arrière possible. Il se trouve à 45% de la corde. Les nervures sont peu espacées (125 mm). The MG-23 first flew in 1955 and was followed down the production line by the improved 1963 ?23SL with taller fin, longer canopy and lowered main wheel. ATC | ||||||
Liens personnalités | Pas de personnalité associée. |
Liens WEB | Site : Alex Sailplane Directory . Note + 1 photo + specs. (2010-04-19 CL) Site : UIUC Applied Aerodynamics Group's . NACA 63-015A fichier DAT. (2010-04-20 JM) Site : UIUC Applied Aerodynamics Group's . NACA 63-015A airfoil. (2010-04-20 JM) |
Livres | Ing. Erwin Musger par KEIMEL, Reinhard (1986) [p. 95-106. Texte + 1 photo + plan 3 vues + specs]. Luftfahrzeugbau in Österreich par KEIMEL, Reinhard (2003) [p. 131-132. Note + photo + plan 3 vues + specs]. Segelflug am Spitzerberg und Hundseimer Kogel par KEIMEL, Reinhard (2010) [p. 105. Une photo]. The world's sailplanes par OSTIV (1958) [p. 10 - 13. Photo + 3-vues + specs + description]. |
Autres sources | Soaring juin 1962 p 20. Photo (publicité) |
